Sinotruk HOWO heavy duty 20000liters water tank truck

Basic Info

Brand: XDR

Applicable Industry: Farms, Other

Out-of-warranty Service: Video Technical Support, Online Support

Video Factory Inspection: Not Available

Mechanical Test Report: Not Available

Marketing Type: Ordinary Product

Core Component Warranty Period: 1 Year

Core Components: Engine, Gearbox, Pump

Drive Form: 6x4

Fuel: Diesel

Gearbox Type: Manual

Old And New: New

Sprinkler Width: 12 - 16m

Emission Standards: Euro 2

Displacement: > 8l, 9726cc

Place Of Origin: China

Warranty Period: 1 Year

Warranty: 1 Year

Drive Type: 6x4

Chassis Brand: SINOTRUK HOWO

Emission Standard: EURO 2

Hose Power: 300HP

GVW: 25000KG

Engine Brand: Weichai

Certificate: CCC ISO

Additional Info

Packaging: WAX

Transportation: Ocean

Place of Origin: CHINA

Supply Ability: 500UNITS/MONTH

Certificate: ISO9001

Port: SHANGHAI,QINGDAO,TIANJIN

Product Description

Water Tank Truck, Water Sprinkler truck, also known as multifunctional greening sprinkler. Used for city roads, large factories, troops, gardens and other units to clean roads, sanitation, dust control, watering, spraying pesticides, etc., in order to achieve the role of beautifying the environment.

The engine drives the gearbox, the extractor installed on the gearbox drives the sprinkler pump, the sprinkler pump generates the main power, and the liquid inside the tank is sprayed out through the pipe network.

Front spraying and back sprinkling, the front is equipped with duck-shaped nozzle or round head nozzle, the back is equipped with cylindrical open sprinkler nozzle or lotus head nozzle, the rear has a working platform, assembled with high-pressure water cannon. The rear can also be fitted with 8 nozzles (optional) water sprayer is generally used for washing the street.

Vehicle Main Dimensions	(L x W x H)mm		9630×2500×3300
	Wheel base (mm)		4600+1350
	Approach/Departure angle(°)		13/12
Weight in KGS	Tare Weight		25000
	Curb Weight		10750
	Front axles loading capacity		7100
	Rear axles loading capacity		16000
Engine		Model	WP10.300E22
		Type	6-cylinder inline, supercharged inter-cooling
		Horse Power（HP)	300
		Engine Displacement	9726
		Emission standard	Euro II
Gearbox		10 forwards & 2 reverse
Tire		12.00R20,10 pieces including one spare tire
Brakes		Air Brake
Steering		6x4 Left hand steering (LHD)
Max. Seed		95km/h
