Shacman 12CBM Road maintance Asphalt Distributor Truck

Basic Info

Model No.: YZR5180GLQSX3

Brand: SHACMAN BRAND

Old And New: New

Gearbox Type: Manual

Emission Standards: Euro 2, Euro 3

Fuel: Diesel

Place Of Origin: China

Additional Info

Packaging: bulk

Productivity: 1000 sets/month

Transportation: Ocean,Land,Air,Express

Place of Origin: HUBEI,CHINA

Supply Ability: 1000 sets/month

Certificate: ISO,CCC

Port: shanghai,qingdao,lianyungang

Product Description

The Shacman 10CBM asphalt distributor truck is a specialized vehicle manufactured by Shacman, a major Chinese commercial vehicle company:

1. Capacity: It has a capacity of approximately 10 cubic meters for asphalt storage.
2. Purpose: This truck is designed to distribute and spray asphalt on roads during road construction and maintenance projects.
3. Key features:
- Stainless steel tank with heating system
- Multiple nozzles for even distribution
- Flow meter for accurate measurement
- Pneumatic or hydraulic control system
- Water tank for cleaning purposes
4. Customization options: Can be customized with different nozzle configurations and capacities based on specific project requirements
5. Applications: Used in road construction companies, municipal works departments, and highway maintenance organizations

Shacman Semi-intelligent 10CBM Asphalt Distributor Truck
Payment Term	30% T/T in advance,70% before shipment
Truck Condition	New
Production capacity	1000 sets/month
Warranty	12 months
Port of Delivering	Shanghai,Tianjing,Lianyungang,Qingdao,Guangzhou,China any port
Overall Dimension	8,500x2,500x3,250 mm
Cabin	Shacman white cabin with AC
G.V.W/Curb weight	18,000/8,900 KGS
Max speed	95 km/h
Wheelbase	5,700 mm
Engine Model	WP6.210E32/210hp/155KW/6,230 ml
Engine type	6 cylinder,water cooling,inter cooling
Fuel	Diesel Euro 3
Transmission	8JS85TM/Manual 8+2 gears
Brake	Air brake
Steering	Power assisted
Tire	10.00R20/6+1 pcs
Tank Capacity	10 cbm
Tank Material	Q245 carbon steel/5mm
Spraying medium	emulsified asphalt, hot asphalt, modified asphalt, modified emulsified asphalt
Asphalt Pump	With High viscosity asphalt insulation pump with hydraulic motor
Hydraulic pump	F563 Aluminum alloy gear pump
Hydraulic system	USA brand proportional flow control valve YZR-2MDKZ100A.00
Burner	Riyalu G20 imported from Italy
Heating method	The tank and pipeline are heated with thermal oil throughout the entire process
Temperature control	Temperature controller
Spraying width	1.2-4.5 M, three overlapping spraying, spraying 0.2-2kg/m ², 28 sets of stainless steel fully electronic control cylinders and pure copper nozzles,manual knob controls the spraying amount
Generator	Gasoline 5500w
Radiator	With radiator
level gauge	Install a floating ball level gauge inside the tank
Metal thermometer	Metal thermometer installed on the exterior of the tank
Remarks	Equipped with circulation and pump in/pump out functions, compressed air cleaning function for asphalt pipelines, and diesel cleaning function
On-board accessories:	English version vehicle instructions, maintenance manual,operation video
