Dongfeng12CBM Asphalt Distributor Truck

Basic Info

Model No.: YZR5180GLQSE3

Brand: DONGFENG BRAND

Emission Standards: Euro 3, Euro 4, Euro 5

Fuel: Diesel

Place Of Origin: China

Additional Info

Packaging: bulk

Productivity: 1000 sets/month

Transportation: Ocean,Land,Air

Place of Origin: HUBEI,CHINA

Supply Ability: 1000 sets/month

Certificate: ISO,CCC

Port: shanghai,tianjing,qingdao

Product Description

The Dongfeng Intelligent 12CBM asphalt distributor truck is a specialized piece of equipment used in road construction and maintenance, particularly for the application of asphalt and other paving materials:
1. Capacity: The "12CBM" designation indicates that it has a capacity of 12 cubic meters for storing asphalt or other paving materials.
2. Manufacturer: Dongfeng is a major Chinese commercial vehicle manufacturer known for producing trucks, buses, and specialty vehicles.
3. Intelligence features: As an "Intelligent" model, it likely includes advanced technology such as:
- Automated control systems for material distribution
- GPS tracking and fleet management integration
- Telematics for remote monitoring and diagnostics
- Advanced safety features
4. Application: This truck is primarily used for:
- Road resurfacing
- Applying tack coat (bituminous primer)
- Distributing seal coats
- Spreading asphalt emulsion

Dongfeng Semi-intelligent 12CBM Asphalt Distributor Truck
Payment Term	30% T/T in advance,70% before shipment
Warranty	12 months
Overall Dimension	8700x2,500x3,250 mm
G.V.W/Curb weight	18,000/8,600 KGS
Wheelbase	4,700 mm
Engine Model	Cummins brand B190 33/190hp/140KW/5,900 ml
Fuel	Diesel Euro 3
Transmission	8JS85E/Manual 8+2 gears
Tire	10.00R20/6+1 pcs
Tank Capacity	12 cbm
Spraying medium	emulsified asphalt, hot asphalt, modified asphalt, modified emulsified asphalt
Asphalt Pump	With High viscosity asphalt insulation pump with hydraulic motor
Burner	Riyalu G20 imported from Italy
Spraying width	1.2-4.5 M, three overlapping spraying, spraying 0.2-2kg/m ², 28 sets of stainless steel fully electronic control cylinders and pure copper nozzles,manual knob controls the spraying amount
Generator	Gasoline 5500w
Remarks	Equipped with circulation and pump in/pump out functions, compressed air cleaning function for asphalt pipelines, and diesel cleaning function
On-board accessories:	English version vehicle instructions, maintenance manual,operation video
